Cylindrical Implant for Upper Lateral Incisor

A 61-year-old man has chronic periodontitis and bruxism (Fig.1).  Immediately after extraction and Clindamycin socket treatment, osteotomy is initiated with a 2 mm pilot drill at 20 mm in the lower 1/3 of palatal wall with normal saline irrigation, followed by 2.5-4 mm reamers at 20 mm (bone saved, Type III bone).  A screw Implant (4.5x20 mm) is placed (45-50 Ncm, Fig.2).  The root measurements were B-L 6.5 mm and M-D 5 mm.  Autogenous bone is mixed SynthoGraft (size 50-500) ~ .3 g and blood.  A 3.5x5 mm abutment is immediately cemented with an immediate provisional.  There is positive bone growth 3 years post cementation (Fig.3 *).  There is no buccal plate bone resorption 3 years 2 months post cementation (Fig.4 CT).
