In order to maintain the stability, a 4.5x17 mm implant is placed without any further modification.  It is in a less ideal trajectory (Fig.6 I).  But the insertion torque is >60 Ncm.  A 3.5x3 mm abutment is placed (A); an immediate provisional is fabricated and temporarily cemented (^).  *: bone graft, which is mainly placed in the buccal gap.

The patient returns for final restoration 6 months postop.  The apical socket radiolucency remains without ill effect (Fig.10 *).  No bone graft was attempted to be placed in the apical socket, since the graft may interfere with implant insertion.
