The implant at #5 is seated ~1 mm deeper (subcrestal mesially (^^); supracrestal distally (^)); allograft is placed around the implants prior to insertion of 6.5x7(5) and 5.5x4(5) mm abutments; last more allograft is added (Fig.9 *, 10).  There is a large space buccally at #3 and 5, since the implants are placed palatally.  Osteogen plug is placed buccally prior to placement of bone graft around the implants.  The implants seem to have been osteointegrated 4.5 months postop (Fig.12).  The gingiva is healthy around the implants without bone loss 3 months post cementation (Fig.13,14).

Control Osteotomy Depth Last Next

Xin Wei, DDS, PhD, MS 1st edition 09/11/2017, last revision 05/12/2018
