Extremely Large Calculus

A 72-year-old woman has severe pain associated with one of three abutments of a long-spanned bridge (Fig.1,2: #22).  The lingual calculus is extremely large (Fig.3 C).  When the bridge is sectioned between #26 and 27, the tooth #22 is easily separated from the socket (Fig.4).  In fact, the large supragingival calculus causes hemorrhagic indentation in the lingual vestibule (Fig.5,6: I).  Due to finance, socket preservation is done at #22 with 6-month collagen membrane buccally and .5-1.5 mm allograft and collagen plug (Fig.6 *).

Return to Lower Canine Immediate Implant, IBS

Xin Wei, DDS, PhD, MS 1st edition 08/30/2016, last revision 01/19/2018
