A final implant (3.8x15 mm) is placed with > 50 Ncm (Fig.4).  Before and after placement of a 4.5x5(3) mm abutment, Vera graft is placed in the remaining socket space (mainly buccal, Fig.5 *).  As routine, an immediate provisional is fabricated with occlusal clearance.  The bone graft appears to remain in place 4.5 months postop (Fig.7).  The bone density around the coronal portion of the implant increases 9 months postop (4 months post cementation, Fig.8).

Thin Buccal Plate Last Next

Xin Wei, DDS, PhD, MS 1st edition 01/26/2018, last revision 04/20/2019
