A 2.5x10(4) mm 1-piece implant is placed with <50 Ncm; since the trimmed implant threads at #5 are exposed (Fig.3), Vanilla graft with Osteogen is placed mesial and distal to the new small implant (Fig.4 *).  The mesial, coronal implant threads at #3, uncovered by the bone (Fig.3), are not exposed by the incision directly, but the bone graft appears to contact them.  There is no bone loss 3.5 months postop (Fig.5,6) or 4 months post cementation (8 months post cementation, Fig.8,9).  There is no sign of periimplantitis.  The implant remains mobile and symptomatic (chewing pain) 14 months post cementation (Fig.10).

Small Does Big Last Next

Xin Wei, DDS, PhD, MS 1st edition 02/18/2020, last revision 06/20/2021
