The center of initial osteotomy will be slightly distal (Fig.3 green), since more upright will be conducted after implant osteointegration.  The initial osteotomy depth will be 11 mm.  To place the implant slightly deeper (subcretal), the depth of the last 2nd drill will be 13 mm with stopper.

Upright Before & After Implantation Last Next Raise Bite

Xin Wei, DDS, PhD, MS 1st edition 11/20/2016, last revision 07/28/2021
