Finally a 5.5x7 mm IBS implant is placed with 30 Ncm (Fig.5).  After placement of Osteogen plug in the apical portion of the sockets, allograft/Osteogen is placed in the remaining sockets (Fig. 5 *).  The latter is partially contained by a 6.5x4(3) mm abutment (A) and ultimately by an immediate provisional.

The implant is mobile 4 months postop (Fig.6).  A 6x2 mm healing abutment is placed.  Although the implant remains mobile 6 months postop, the bone seems to have become denser around the implant (Fig.7-9).  A healing screw is placed.

The implant seems to have osteointegrated 8 months postop (Fig.10).  Impression is taken following re-placing a 6.5x4(3) mm abutment.

Initial Depth Last Next

Xin Wei, DDS, PhD, MS 1st edition 06/13/2017, last revision 04/18/2018
