After placing allograft for sinus lift (Fig.6 >), a 5x11 mm IBS implant is placed with insertion torque ~ 50 Ncm.  A 6x4(3) mm pair abutment is placed, followed by bone graft in the remaining sockets (*).

The bone density in the mesial socket appears to increase and becomes more homogenous 3 months postop (Fig.13 *).  Impression is taken for final restoration.

There is bone formation in the sinus distal to the implant 6 months post cementation (Fig.14 *) with the osseous tissue having grown into between the threads (arrow).

Palatal Socket Last Next 1-Year

Xin Wei, DDS, PhD, MS 1st edition 08/17/2016, last revision 06/03/2018
