After reusing the 1.6 mm drill for 11 mm, Magic Drill 3.3 mm and final drill are utilized to finish osteotomy.  A 4x11 mm IBS implant is placed with better trajectory and insertion torque > 50 Ncm (Fig.2).  After further apical placement of the implant (Fig.3 arrow, 6 turns of torque wrench), a 4.5x5.7(3) mm abutment (A) and bone graft (*) are placed.  The coronal bone loss is minimal 10 weeks postop (Fig.7).

Narrow Implant with High Torque Last Next Xin Wei, DDS, PhD, MS 1st edition 02/16/2017, last revision 08/15/2018
