After placing bone graft into the sinus and the osteotomy (Fig.2 black *), a 5x9 mm implant is placed with >30 Ncm.  Second round of bone graft is placed around the implant, including DB defect (white *).  Then a 5x4(2) mm pair abutment is placed, followed by the third round of bone graft (Fig.3 *).  If the abutment were placed prior to the 2nd round of the bone graft, the latter would be unable to reach the deepest implant threads or the defect.

Seating     Last     Next

Xin Wei, DDS, PhD, MS 1st edition 02/07/2020, last revision 06/02/2020
