A 4.5x17 mm tissue-level implant is placed (Fig.3 I) with insertion torque >60 Ncm.  Allograft and Osteogen are placed around the bulging buccal and lingual plates (*).  Collagen membrane with a hole in the center is fixed around a 3.5x5 mm abutment (A).  An immediate provisional is fabricated mainly for wound protection and perio dressing fixation.  The patient returns 3 months postop; the bone graft appears to have been displaced mesioocclusally (Fig.4 arrow). Fig.7: 7 months post cementation.

Dense Bone Last Next Xin Wei, DDS, PhD, MS 1st edition 01/17/2016, last revision 01/19/2019
